FEATURES
TECHNICAL DATA
| Code | Power | LED | Dim | Input | CCT | Lumen | CRI | Beam Angle | PF | PIR Sensor | Detection Angle |
Detection Brightness |
Detection Distance |
Detection Duration |
| WL-YD2R-230P |
30W |
SMD2835 | No |
110-130V~60Hz |
3000/4000/6500K |
1750-1900lm(BK)/2000-2500lm(WH) |
>80Ra |
100°/head |
>0.7 |
Available |
150° |
5-2000Lux |
12m max |
10s-10min
|
CONSTRUCTION
| Code | Driver | Body Material | Color | Weight | Waterproof |
| WL-YDR-230P |
Internal |
Plastic+Aluminum |
White/Black | WET LOCATION USE |
PACKAGING INFORMATION
| Code | Unit/Inner Box | Inner Box Dimensions (L*W*H) |
Inner Box G.W. | Unit/Masterbox | Masterbox Size (L*W*H) |
Masterbox G.W. | Masterbox Volume |
| WL-YDR-230P |
1pc |
235*195 *145mm |
16pcs |
48.5*45.5*41.5cm |
0.092m³ |
