DL-SQ325A-108LND3 4/6/8W

   FEATURES

  • Lens Version
  • Dimmable+3CCT
  • 3 Wattage Turnable
  • Dimmable+3CCT
  • Economical DOB solution
  • Slim with Only 29mm Height
  • CE UKCA IP44
  • 2 years warranty
Contact now Download
  • sq325-p

PRODUCT DESCRIPTION

TECHNICAL DATA

Code Power LED Dim Input CCT Lumen CRI Beam Angle PF
DL-SQ25R-107LND3
 7W SMD2835
 Yes
 220-240V~50/60Hz
 3000/4000/6500K
 480/560/500lm
 >80Ra
 110°
 >0.9
DL-SQ325R-108LND3 4/6/8W SMD2835 Yes 220-240V~50/60Hz 3000/4000/6500K 400/600/800lm >80Ra 110° >0.7
DL-SQ325A-108LND3 4/6/8W SMD2835 Yes 220-240V~50/60Hz 3000/4000/6500K 400/600/800lm >80Ra 60° >0.7



CONSTRUCTION

Code Driver
 Body Material Trim Color Dimension Weight Cutout IP Rating
DL-SQ25R-107LND3
 DOB
 Nylon+Aluminum
  White/Black/Nickel/Chrome
 D85*29mm
 0.047kg(WH)/0.064kg(NK/CH)
 66-75mm
 IP44
DL-SQ325R-108LND3 DOB PP+PC+Al  White/Black/Nickel/Chrome D85*29mm 0.051kg 68-78mm IP44
DL-SQ325R-108LND3 DOB PP+PC+Al  White/Black/Nickel/Chrome D85*29mm 0.058kg 68-78mm IP44



PACKAGING INFORMATION

Code Unit/Inner Box Inner Box Dimensions
(L*W*H)		 Inner Box G.W.  Unit/Masterbox Masterbox Size
(L*W*H)
 Masterbox G.W. Masterbox Volume
DL-SQ25R-107LND3
 1pc
 95*95*45mm 0.069kg(WH)/0.086kg(NK/CH) 100pcs 50.5*40.5*26.5cm 7.60kg(WH)/9.30kg(NK/CH) 0.054m³
DL-SQ325R-108LND3 10pcs 30.5*10.5*9cm 0.36kg(WH/BK)/0.72kg(NK) 200pcs(WH/BK)/160pcs(NK) 48*44.5*32.5cm(WH/BK)/44.5*38.5*32.5cm(NK) 12.9kg(WH/BK)/12.17kg(NK) 0.069m³(WH/BK)/0.056m³(NK)
DL-SQ325A-108LND3 10pcs 30.5*10.5*9cm   200pcs 48*44.5*32.5cm   0.070m³
