FEATURES
TECHNICAL DATA
| Code | Power | LED | Dim | Input | CCT | Lumen | CRI | Beam Angle | PF |
| DL-SF30B-108D3 |
8W |
SMD2835 |
Yes(Triac) |
220-240V~50/60Hz |
3000/4000/5700K |
680/720/700lm | >80Ra |
120° |
>0.7 |
| DL-SF30-108D3 | 8W | SMD2835 | Yes(Triac) | 220-240V~50/60Hz | 3000/4000/6500K | 640lm | >80Ra | 110° | >0.7 |
CONSTRUCTION
| Code | Driver |
Body Material | Trim Color | Dimension | Weight | Cutout | IP Rating |
| DL-SF30B-108D3 | DOB |
PA+PC+Al | White/Nickel |
D106*H40mm |
kg |
90-100mm | IP44 |
| DL-SF30-108D3 | DOB |
PA+PC | White/Nickel | D113*H32.4mm |
kg | 90-100mm | IP44 |
PACKAGING INFORMATION
| Code | Unit/Inner Box | Inner Box Dimensions (L*W*H) |
Inner Box G.W. | Unit/Masterbox | Masterbox Size (L*W*H) |
Masterbox G.W. | Masterbox Volume |
| DL-SF25-106D3 |
6pc |
21*10.5*10.5cm | 0.55kg |
144 pcs |
44.5*43.5*34.5cm | 13.93kg | 0.067m³ |
| DL-SF30-108D3 | 6pc | 21*11.8*11.8cm | 0.69kg | 108 pcs | 43.5*37.5*38.5cm | 13.13kg | 0.063m³ |
